High quality GYTA single mode outdoor armored Fiber optical cable

High quality GYTA single mode outdoor armored Fiber optical cable

Regular price $1.00
Regular price Sale price $1.00
Sale Sold out
Shipping calculated at checkout.
Pls contact for order

High quality GYTA single mode outdoor armored Fiber optical cable

Technical Parameters:
Cable Type Fiber Count Tubes Fillers Cable Diameter mm Cable Weight kg/km Tensile Strength Crush Resistance Bending Radius
Long/Short Term  Long/Short Term Static/ Dynamic
N N/100mm mm
GYTA-2~6  2~6 1 4 9.7 90 600/1500 300/1000 10D/20D
GYTA-8~12  8~12 2 3 9.7 90 600/1500 300/1000 10D/20D
GYTA-14~18  14~18 3 2 9.7 90 600/1500 300/1000 10D/20D
GYTA-20~24  20~24 4 1 9.7 90 600/1500 300/1000 10D/20D
GYTA-26~30  26~30 5 0 9.7 90 600/1500 300/1000 10D/20D
GYTA-32~36  32~36 6 0 10.2 104 1000/3000 300/1000 10D/20D
GYTA-38~48  38~48 4 1 11 117 1000/3000 300/1000 10D/20D
GYTA-50~60  50~60 5 0 11 117 1000/3000 300/1000 10D/20D
GYTA-62~72  62~72 6 0 11.5 126 1000/3000 300/1000 10D/20D
GYTA-74~84  74~84 7 1 13.4 154 1000/3000 300/1000 10D/20D
GYTA-86~96  86~96 8 0 13.4 154 1000/3000 300/1000 10D/20D
GYTA-98~108  98~108 9 1 14.8 185 1000/3000 300/1000 10D/20D
GYTA-110~120  110~120 10 0 14.8 185 1000/3000 300/1000 10D/20D
GYTA-122~132  122~132 11 1 16.9 228 1000/3000 300/1000 10D/20D
GYTA-134~144  134~144 12 0 16.9 228 1000/3000 300/1000 10D/20D
GYTA-146~216  146~216 16.9 233 1000/3000 300/1000 10D/20D
Description:
The fibers, 125μm,are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire, sometimes sheathed with polyethylene (PE) for cable with high fiber count, locates in the center of core as a metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular cable core. An Aluminum Polyethylene Laminate (APL) is applied around the cable core, which is filled with the filling compound to protect it from water ingress. Then, the cable is completed with a PE sheath.
Characteristics
        · Good mechanical and temperature performance
        · High strength looes tube that is hydrolysis resistant
        · Special tube filling compound ensure a critical protection of fiber
        · Specially designed compact structure is good at preventing loose tubes from shrinking
        · PE sheath protects cable from ultraviolet radiation
        · The following measures are taken to ensure the cable watertight:
                - Steel wire used as the central strength member
                - Loose tube filling compound
                - 100% cable core filling
                - APL moisture barrier
Standards:
        GYTA cable complies with Standard YD/T 901-2001as well as IEC 60794-1.
Storage/Operating Temperature : -40℃ to + 70℃
