COMWAY C6S FTTx PAS Fusion Splicer – Precision Built for Last-Mile Fiber
The COMWAY C6S is a professional FTTx-optimized fusion splicer featuring PAS (Profile Alignment System) high-precision alignment technology. Designed specifically for FTTH, FTTB, and FTTC last-mile deployments, the C6S delivers fast, reliable splices with 750X magnification and a rugged field-ready build — all at a price point that makes it the go-to choice for FTTx contractors and telecom installers.
Why Choose the COMWAY C6S?
- PAS High-Precision Alignment: Profile Alignment System ensures accurate fiber alignment for consistent low-loss splices (SM: 0.02dB) across all standard fiber types
- FTTx-Optimized Package: Includes a dedicated Drop Cable Stripper — essential for FTTH drop cable preparation, not included with most standard splicers
- 750X Single-Axis Zoom: Ultra-high magnification for precise fiber inspection and alignment verification in the field
- 5-Second Splice Time: Fast 5-sec splice and 8-sec heating time to maximize productivity on large-scale FTTx rollouts
- Built Tough: Waterproof, dust-proof, and anti-shock construction for reliable performance in outdoor and aerial environments
- GPS Anti-Theft Option: Optional GPS tracking to protect your equipment on job sites
- Multi-Function Design: Operates as both a fiber endface melter and fusion splicer
Ideal Applications
- FTTH / FTTB / FTTC last-mile fiber installation
- Drop cable splicing for residential fiber connections
- Telecom access network deployment and maintenance
- MDU (Multi-Dwelling Unit) fiber distribution
- ISP network build-out and expansion projects
C6S vs. C10S – Which Should You Choose?
| Feature | C6S (PAS) | C10S (Core Alignment) |
|---|---|---|
| Alignment Method | PAS (Profile Alignment) | 6-Motor Core Alignment |
| Best For | FTTx / last-mile deployment | Backbone / 5G / high-precision |
| Drop Cable Stripper | Included | Not included |
| G.654E Support | No | Yes |
| Splice Loss (SM) | 0.02dB | 0.02dB |
| Splice Time | 5 sec | 5 sec |
| Battery | 5600mAh | 5600mAh |
| Price Point | More affordable | Premium |
Technical Specifications
| Parameter | Specification |
|---|---|
| Fiber Alignment | High Precision PAS (Profile Alignment System) |
| Fiber Types | SM (G.652), MM (G.651), DS (G.653), NZ/NZDS (G.655), BI (G.657) |
| Splice Loss | SM: 0.02dB | MM: 0.01dB | DS: 0.04dB | NZ/NZDS: 0.04dB | BI: 0.02dB |
| Splice Time | 5 sec (SM Fast) / 10 sec (SM G652) |
| Heating Time | 8 sec (micro sleeves) / 12 sec (slim 60/40mm) |
| Fiber Magnification | 750X single axis (zoom) / 300X dual axis |
| Display | 4.3-inch high-resolution display |
| Battery | 5600mAh, 350+ splice & heat cycles |
| Splice Programs | Max. 200 splice / 30 heating programs |
| Data Storage | Max. 20,000 splice records + 800 images |
| Fiber Diameter | Cladding: 80–150μm | Coating: 100–3000μm |
| Operating Conditions | -10°C to +50°C | 0–95% humidity | 0–5000m altitude | Wind up to 15m/s |
| Dimensions & Weight | 156 × 135 × 149mm | 2.0kg (2.5kg with battery) |
| Protection | Waterproof, Dust-proof, Anti-shock |
| Optional Features | GPS Tracking |
| Electrode Life | 5,000 ARC discharges |
| Warranty | 1 Year |
Package Contents
- COMWAY C6S Fusion Splicer
- High-Precision Cleaver C109
- Fiber Stripper
- Drop Cable Stripper (FTTx-specific)
- Extra Electrodes
- High-Capacity 5600mAh Battery
- AC Adapter + AC Adapter Cable
- DC Charging Cable
- USB Cable
- Cooling Tray
- Carrying Case
- Hand Strap + Shoulder Strap
- Alcohol Bottle
- User Guide
Frequently Asked Questions
Q: What is PAS alignment and how does it differ from core alignment?
A: PAS (Profile Alignment System) aligns fibers by analyzing the outer profile/cladding of the fiber using image processing. Core alignment directly aligns the fiber cores. PAS is highly effective for standard FTTx fiber types and offers excellent splice loss (0.02dB SM), while core alignment is preferred for specialized or high-precision backbone applications.
Q: Why does the C6S include a Drop Cable Stripper?
A: The C6S is specifically designed for FTTx deployments where drop cables (flat or figure-8 cables used for residential connections) are commonly used. The included Drop Cable Stripper makes it a complete solution for FTTH installers without needing additional tools.
Q: What fiber types does the COMWAY C6S support?
A: The C6S supports SM (G.652), MM (G.651), DS (G.653), NZ/NZDS (G.655), and BI (G.657) — covering all standard fiber types used in FTTx and access network deployments.
Q: Should I choose the C6S or the C10S?
A: Choose the C6S if you primarily do FTTx/FTTH last-mile work and need a cost-effective, reliable splicer with drop cable support. Choose the C10S if you work on backbone networks, 5G infrastructure, or require 6-motor core alignment for the highest precision and G.654E fiber support.
Q: What warranty does the COMWAY C6S come with?
A: The C6S comes with a 2-year manufacturer warranty. Contact us at info@splicermarket.com for support.
